38
18. CONTROL HEAD PARTS, MODELS 6072-4453
18.2 Parts List
Diagram Part No. Description Qty.
1 FBSC-040312 Stop bolt 1
FNSC-0103 Nut, stop bolt 1
2 PPB-002 Bearing 1
3 FBCF-010830 Bolt, suspension 2
FNSF-0208-2 Nut, suspension 2
4 FBCF-010830Y Bolt, yoke (2003 & older Control Heads) 1
FBCC-021026 Shoulder bolt (2004 & newer Control Heads) 1
FNSF-0208Y Nut, yoke 1
5 BB-050 Casting, base (2003 & older Control Heads) 1
BB-051 Casting, base (2004 & newer Control Heads) 1
BB-060 Casting, cover (Not shown) 1
6 BB-064 Casting, trip block, machined 1
7 BB-066 Casting, yoke (2003 & older Control Heads) 1
BB-068 Casting, yoke (2004 & newer Control Heads) 1
8 BB-012 Catch 1-1/2" long, small 1
9 FPCS-005 Clevis pin, bearing 1
10 FPCS-003 Clevis pin, catch 1
11 FPCS-005 Clevis pin, long 1
12 FPCS-002 Clevis pin, short 1
13 FPCS-001 Clevis pin, solenoid 1
14 FPCS-005 Clevis pin, swivel 1
15 BB-003 Link, long 2
16 BB-004 Link, short 2
17 BB-005 Link, slotted 1
18 BB-006 Link, spring 1
19 BB-002A Reel, spring, std., 6072-1821 1
BB-019A Reel, spring, h.d., 2024-4453 1
20 FBSF-070314 Screws, cover 4
FNSF-0203 Nuts, cover 4
21 FTAG-003 Shackle, top 1
22 BB-001A Solenoid and Piston, c/w bolts and nut, 24 volt 1
23 BB-021 Spring, catch 1
24 BB-022 Spring, return 1
25 PP-010 Terminal block 1
FSS-060206 Screw, terminal block 1
26 BB-386 Trip line assy., 2024-4453 1
BB-380 Trip line assy., 6072-1821 1
27 LB-001 Spec. label, cover (Not shown) 1
28 LB-004 Warning label, reel (Not shown) 1
29 BB-067 Wire, lead 1
30 FBSCO40314 10-24 X 1 1/4 Pan Phil, SS, Machine Screw 2
31 FPSS-003 Dowel pin, Link Stop 1
BB-580-12 Control Head, complete, 6072 only 1
BB-580 Control Head, complete, small (8096-1821) 1
BB-585 Control Head, complete, medium 1
