54
25.2 Parts List
Diagram # Part No. Description Qty.
1 BB-360-S Deployment Cable Assy, 2024 1
BB-361 Deployment Cable Assy, 2732-4453 1
BB-364 Deployment Cable Assy, 5566 1
BB-370 Deployment Cable Assy, 6578/7590 1
BB-372 Deployment Cable Assy, HL5000 1
BB-373 Deployment Cable Assy, HL7600 1
BB-374 Deployment Cable Assy, HL9800 1
2 BB-456 Hub, Medium Casting, Machined, 2024-5566 1
BB-461 Hub, Large Casting, Machined, 6578-HL9800 1
3 BB-330 Restrainer Brackets 2
4 BB-310 Cables Hub Restrainer 2024 2
BB-311 Cables Hub Restrainer 2732 2
BB-312 Cables Hub Restrainer 3542 2
BB-313 Cables Hub Restrainer 4453 2
BB-314 Cables Hub Restrainer 5566 2
BB-320 Cables Hub Restrainer 6578/7590 2
BB-322 Restrainer Cable Assy, Hub, HL5000 2
BB-323 Restrainer Cable Assy, Hub, HL7600 2
BB-324 Restrainer Cable Assy, Hub, HL9800 2
5 BB-465 Shell Brackets, 2024-5566 8
BB-466 Shell Brackets, 6578-HL9800 8
7 BB-410 Spoke Tube IDS, 2024 8
BB-411 Spoke Tube IDS, 2732 8
BB-412 Spoke Tube IDS, 3542 8
BB-413 Spoke Tube IDS, 4453 8
BB-414 Spoke Solid IDS, 5566 8
BB-415 Spoke Solid IDS, 6578 10
BB-420 Spoke Solid IDS, 7590 10
BB-422 Spoke Solid IDS, HL5000 10
BB-423 Spoke Solid IDS, HL7600 10
BB-424 Spoke Solid IDS, HL9800 10
8 BB-469 IDS Bracket Wear Strip 8
9 FPCC-020 Clevis Pin, 2024-5566 (cast and welded hub) 16
FPCC-020 Clevis Pin, 6578-HL9800 (welded hub) 20
FPCC-023, FPCC-020 Clevis Pin, 6578-HL9800 (cast hub) 10 (of each part #)
FBCF-010522 Bolt, 5/16" UNF (2004 & newer) 10
FNAN-364524 LockNut, 5/16" UNF (2004 & newer) 10
FWS-02052 Washer, 5/16" (2004 & newer) 20
10 FPDC-002 Cotter Pin, 2024-5566 16
FPDC-002 Cotter Pin, 6578-HL9800 20
11 FWS-0605-06 Flat Washer, 2024-5566 16
FWS-0605-06 Flat Washer, 6578-HL9800 20
12 FWR-0105 Spacer, Rubber, 2024-5566 32
FWR-0105 Spacer, Rubber, 6578-HL9800 40
25. IDS SYSTEM, MODELS 2024-HL9800
