Seiko 7K52 - HOW TO USE THE DIVER EXTENDER

English
30
HOW TO USE THE DIVER EXTENDER
Flap
Clasp
12 o’clock
side
Two-piece
foldover portion
Upper cover
6 o’clock
side
➡
2
➡
1
➡
3
➡
4
➡
➡
➡
➡
6
Approx. 2 cm
5
● To extend the band length
1
Lift up the flap.
2 Press the button to open the clasp.
* Then, push the flap back to the normal position for
safety’s sake.
3 Pull the two-piece foldover portion until it clicks
loose.
4 Slide the upper cover in the direction of the
arrow, and then,
5 pull it up to extend the two-piece foldover
portion to the full.
6 Close the clasp, and then, the flap.
● To change back the band length
Fold the two-piece foldover portion, and hook the
upper cover on to the shaft of the flap. Then, pull
the bracelet hard until the two-piece foldover
portion fixed in position.
