For wall mounting works as follow:
- make on the wall n. 2 holes with a diameter of 5 mm each with an
apart distance and minimum distance from the surrounding surfaces,
as shown in Figure below,
- insert the 5 mm plugs into the holes
- fasten the screws to the plugs up to 5 mm from the surface of the wall
- position the telephone against the wall over the screws so that the
screws heads insert in the larger part of the keyholes cutouts and
block the telephone by sliding it down onto the screws.
7.2 Battery installation
This telephone requires 4 batteries LR6 (AA) 1.5V as back-up power source.
Open the battery door by screw driver and place the batteries into the battery
compartment. Make sure the batteries are placed properly and with the correct
polarity, printed on the bottom of the batteries compartment. Close the battery
door.
