CONTROL PANEL OVERVIEW
KEY
FUNCTION
START/STOP
Starts, restarts or stops the counting process.
CLR
Clears the counting number display.
ADD
Switches between ADD mode and NORM (or NOM) mode.
SPD
Changes the counting speed.
1 - 9
Number buttons for selecting the batch stop setting.
0/C
Clears the batch stop setting or functions as 0 when selecting the batch stop
setting.
UV
Turns on/off the UV counterfeit detection feature. (Models S-1615 and S-
1625)
MG
Turns on/off the MG counterfeit detection feature. (Model S-1625 only)
Model S-1600
Model S-1615 with Ultraviolet Counterfeit Detection
Model S-1625 with Ultraviolet and Magnetic Counterfeit Detection
