Senal PMC-II User Manual

6
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
Connecting to a Computer
Setup Instructions
Important! Make sure your powered monitors are turned off so that loud noises or pops
won’t occur when making the connections to the PMC-II.
Connecting to a Computer
To connect the PMC-II to a computer or other device with a 1/8ʺ TRS stereo output, follow
these steps:
1. With a 1/8″ TRS Stereo Mini to 1/8″ TRS Stereo Mini cable, connect the audio output jack
of your computer or device to the stereo mini input of the PMC-II.
Stereo Stereo
R L
OutputInput
Passive Monitor Controller
R L
XLR/F
1/8″ TRS Stereo Mini
XLR/M
