• Disassemble the upright vacuum cleaner in reverse sequence. To remove the floor nozzle Aqs it is
first necessary to press button Aqa and to hold it pressed down. This will release the nozzle Aqs
and only then will it be possible to take it off. To take the hand vacuum cleaner off the body of the
upright vacuum cleaner A6, first press the button A5. Hold down the button A5 and take off
the hand vacuum cleaner.
3. Assembling and disassembling the charging base
• Assemble the charging base Aql by inserting the top part into the bottom part as shown in figure
D. The connection of these two parts is signalled by an audible snap.
D
• When disassembling the charging base Aql, it is necessary to first release the clip on the underside
of the base Aql. Slide the clip in the direction of the arrow shown on the underside of the base Aql
and then take the top part of the base Aql off the bottom part.
E
1
1 Clip
