16 | AC 3
Specifications
Specifications
In complicance with
Approved by
Frequency range AC 3: 500 to 870 MHz
AC 3-US: 470 to 698 MHz
Distribution attenuation 0 dB (±1 dB)
RF input power max. 30 mW per input
Impedance 50
Supply voltage 13.8 V DC
(with NT 3-1 table top power
supply)
Total current consumption max. 3.4 A
(with connected transmitters)
Supply voltage for trans-
mitters at
RF IN 1 to
RF IN 4
11.4 V (protected from reverse
feed), 350 mA
Relative humidity 5 to 95%
Operating temperature range –10°C to +55°C
Storage temperature range –20°C to +70°C
Dimensions of housing approx. 212 x 168 x 43 mm
Weight approx. 1470 g
Europe EMC EN 301489-1/-9
Radio EN 300422-1/-2
Safety EN 60065
Canada Industry Canada RSS 210,
IC: 2099A-AC3,
limited to 698 MHz
USA 47 CFR Part 74
FCC-ID: DMOAC3,
limited to 698 MHz
Australia
