Technical data
HMEC 305 앚HMEC 305-C 앚HMEC 322 앚HMDC 322
Headphones
Transducer principle dynamic
Ear coupling circumaural, closed
Frequency response 45–15,000 Hz
Nominal impedance active/passive 300/150 Ω, mono 앚 50/35 Ω, mono
Attenuation (active and passive) > 25 – 40 dB
Max. sound pressure level 120 dB (± 5%)
Contact pressure approx. 10 N
Microphone incl. preamplifier
Transducer principle electret mic capsule, 앚 dynamic mic capsule,
noise-compensated, 앚 noise-compensated,
MKE 45-1 앚 M-87/AIC
Frequency response 300–5,000 Hz 앚 500–4,000 Hz
Sensitivity – 앚 1.8–4 µV / 74 dB at 5 Ω
Max. sound pressure level 120 dB 앚 –
Min. terminating impedance 150 Ω 앚 –
Output voltage 400 mV ± 3 dB at 114 dB (as per RTCA/DO 214) 앚 –
Supply voltage typ. 16 V DC (8 – 16 V DC, approx. 8 – 25 mA, as per RTCA/DO 214) 앚 –
