15
English
Additional information for hearing aid acousticians
Adjusting the earbow pressure
Loosen the screw at the rear of the stethoset receiver. Move the
screw in the long hole to the desired position (continuously
adjustable).
1 = Low earbow pressure
2 = High earbow pressure
Tighten the screw.
Adjustments for hearing disabilities
Turn the operating control fully counterclockwise (0). Remove
the operating control by carefully lifting it over the "snap-in
pins" on the inside. Use the 4 potentiometers on the circuit
board to individually adjust the max. volume and the bass
response for the left and right headphone system.
1 = Max. volume R/L
2 = Bass response R/L
2
1
1
2
set 810_93286_0106_Sp7.book Seite 15 Donnerstag, 19. April 2007 4:29 16
