8 Care and maintenance
SKM 1091 DIGITAL handheld transmitter
The SKM 1091 DIGITAL’s sound inlet basket should be cleaned from time to
time.
씰 Unscrew the inlet basket (turn anti-clockwise) and remove it.
씰 Rinse foam protection and sound inlet basket with warm water.
씰 Dry both foam protection and sound inlet basket with a hairdryer.
Note:
Do not use any cleansing agents or solvents. Do not touch the micro-
phone contacts.
Take off the sound inlet basket carefully in a straight line taking care
of the microphone capsule!
씰 Screw the sound inlet basket back tight on the SKM 1091 DIGITAL
transmitter.
9 Connector assignment
1/8” stereo jack plug 1/4” jack plug, unbalanced,
(lockable), SK 1093 EM 1090
XLR-3 connector, balanced, DC connector/Power supply
EM 1090
