Operation
56
Connecting the receiver to the camera
►
▷ Plug the camera cable’s screw-on jack plug into the jack socket on the
receiver.
▷ Lock the jack plug by screwing down the coupling ring.
If the jack plug is not firmly locked, crackling noise can appear in the
audio signal.
▷ Insert the receiver into the hot shoe adapter.
▷ Slide the hot shoe adapter onto your camera.
▷ Plug the camera cable’s simple jack plug into the jack socket on your
camera.
Switching on the transmitter and receiver
►
▷ Briefly press the button on the transmitter and the button on the receiv-
er.
The status LEDs indicate the charge level for four seconds.
▷ During these four seconds, check that the transmitter and receiver are
sufficiently charged.
> 75%
5% – 75%
< 5%
If the status LED remains red, you should charge the rechargeable bat-
