SenTech STC-TB83USB-ASH - Specifications

STC – TC83USB-ASH
STC – TB83USB-ASH
I. Specifications
A. Electronic Specifications / Mechanical Specifications / Environmental Conditions
Product
STC-TC83USB-ASH
STC-TB83USB-ASH
Electronic
Specifications
Imager
1/3” Interline XGA Color
Progressive CCD: ICX204AK
1/3” Interline XGA Monochrome
Progressive CCD: ICX204AL
Total Picture Elements
1077 (H) x 788 (V)
Effective Picture Elements
1034 (H) x 779 (V)
Chip Size
5.80 (H) x 4.92 (V) mm
Cell Size
4.65 (H) x 4.65 (V) µm
Scanning System
Progressive
Scanning Methods
Full Scanning, 1/1 Partial
Scanning, ½ Partial Scanning, ¼
Partial Scanning, Variable Partial
Scanning
Full Scanning, 1/1 Partial
Scanning, ½ Partial Scanning, ¼
Partial Scanning, Variable Partial
Scanning, Binning, Binning 1/1
Partial Scanning, Binning ½
Partial Scanning, Binning ¼
Partial Scanning, Binning Variable
Partial Scanning
Pixel Frequency
29.5 MHz
Maximum
Frame Rate
Full Scanning
29.18 fps
½ Partial
60.02 fps
¼ Partial
120.35 fps
Resolution
1024 (H) x 768 (V) (Full Scanning)
1024 (H) x 344 (V) (1/2 Partial Scanning)
1024 (H) x 136 (V) (1/4 Partial Scanning)
S/N Ratio (Standard Deviation)
≤ 10 digit (Factory Default Gain Setting)
Minimum Scene Illumination
1.5 Lux at F1.2
0.5 Lux at F1.2
Sync. System
Internal
Electronic Shutter
Auto / Manual (Software Selectable)
Gain
Auto / Manual (Software Selectable)
Gamma
Manual (Software Selectable)
White Balance
Auto / Manual / One shot
(Software Selectable)
-
Trigger Mode
Free-run / Edge Preset Trigger / Pulse Width Trigger / Start & Stop
Trigger (Software selectable)
Input / Output
USB2.0 High Speed
Power
Supply
Input Voltage
+5V through USB connector or 12Pin connector
Consumption
Less than 330 mA
Mechanical
Specifications
Dimensions
51 (W) x 51 (H) x 35.7 (D) mm
Lens Mount
CS Mount
Input / Output Connector
12 Pin Connector (Hirose) / 2.5 mm Pin Jack
Tripod
2 screws on the bottom plate
Weight
Approximately 130 g
Environmental
Conditions
Temperature
and Humidity
Operational
Temperature: 0 to 40⁰C;
Relative Humidity: 0 to 85% (No Condensation)
Storage
Temperature: -30 to 65⁰C;
Relative Humidity: 0 to 90% (No Condensation)
RoHS
RoHS Compliant
Product Specifications 4 of 11 Rev 1.1
