STANDARDS
■
Low Voltage Directive 2006/95/EC
■
EMC Directive 2004/108/EC: EN 61326
■
WEEE Directive 2012/19/ EU
■
RoHs Directive 2011/65/EU
WIRING AND CONNECTIONS
L Mains supply 230 VAC ± 10 % - 50 / 60 Hz
N Neutral
PE Earth terminal
L1 Unregulated output (230 VAC/max. 2 A)
U1, U2 Regulated output to the motor
SW Remote / timer switch
A Modbus RTU (RS485) signal A
/B Modbus RTU (RS485) signal /B
+V Supply output + 12 VDC/1 mA
Ai
Analogue input:
(0—10 VDC/0—20 mA) or (10—0 VDC/20—0 mA)
Logic input (Timer functionality):
(min. 2,5 VDC and > 30 ms )
GND Ground
Connections
Cable cross section: max. 2,5 mm
2
Cable gland clamping range: 3—6 mm / 5—10 mm
EVS
ELECTRONIC FAN SPEED
POWER MODULE WITH MODBUS RTU
