24
7. Maintenance
Warnings and Cautionary Advice
 Call Sentier customer service if you think your device needs repair
 Do not perform your own maintenance on the Vetcorder;
performing your own repairs will void the warranty.
7.1 Warranty
The Vetcorder is warranted to be free from manufacturer defects in
materials and workmanship within the warranty period, which starts
upon your date of purchase:
 1-year warranty on the Vetcorder Monitor and Red Case.
 6-month warranty on all Vetcorder Accessories.
7.2 Battery
This monitor is designed to operate on rechargeable Lithium-ion battery.
The battery charges automatically when the monitor is connected to AC
power or devices that can output electronic power through USB
connector, such as personal computer and mobile battery bank etc.
On-screen battery symbols indicate the battery status as follow:
The battery is fully charged.
The solid portion represents the remained battery energy. If the
solid portion moves from left to right, then it means that the
battery is being charged.
Indicates that the battery is almost depleted and needs to be
charged immediately. If not charged the device will shut down
automatically.
To charge the battery,
1. Connect the smaller end of the USB charging cable to the connector
at top of monitor. The Vetcorder may not be used while charging.
25
2. Connect the other end of the USB charging cable to the USB
charging port.
3. Please make sure that the LED is blue and press the Home button to
enter the Main Screen, if needed.
4. When the LED turns to green, it means the battery is fully charged.
Then you can unplug the USB cable.
Warnings and Cautionary Advice
 The device cannot be used for any measurement during charging.
 Use charging adapter provided by manufacturer, or USB charging
devices that comply with the standard of IEC 60950.
8. Clean the device weekly, carefully swabbing the device surface with
a soft cloth or cotton swab with rubbing alcohol. Do not pour
alcohol or spray anything directly onto or into the device. Do not
submerge in any liquid.
Warnings and Cautionary Advice
 Call Sentier customer service if you think your device needs repairs.
 Do not perform your own maintenance on the Vetcorder;
performing your own repairs will invalidate the warranty.
26
8.1 Trouble Shooting
Problem
Possible Cause
Solution
The device does not
turn on.
1.
The battery may be
low.
2. The device might be
damaged
1. Charge the battery
and try again.
2. Please contact
Sentier
Low
battery
indicator is blinking
The battery is low.
Charge the battery and
try again.
The
ECG
waveform
amplitude is small
The
lead you cho
se
is
not suitable
.
Change another
lead
and try again.
ECG
waveform
drifts
1.
The pressure
exerted on the
electrode(s) is not
stable or too much.
2. Leg or body may be
moving.
1.
Reattach
electrode(s), hold the
device stably and
gently.
2. Try to keep animal
perfectly still and test
again.
The app cannot find
the device.
The Bluetooth may
not be turned on.
T
urn on the Bluetooth
on the second page of
Main
Screen
.
“
Error 4”
The SpO
2
or ECG
cable
might be damaged
.
Please contact
Sentier
“System Error”
occurred.
Software or hardware
failure.
Restart the device
and
measure again. If the
error persists, contact
Sentier
No
sound
during
ECG and SpO
2
measurement
.
The
speaker
is muted.
Unmute the speaker in
the Settings menu.
Temperature value
is too high or to
low
.
The temperature cable
might be damaged
Please contact Sentier
34
Recommended separation distances between portable and mobile RF communications equipment and the device
The Vetcorder is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The
customer or the User of the Health Monitor can help prevent electromagnetic interference by maintaining a minimum distance
between portable and mobile RF communications equipment (transmitters) and the monitor as recommended below,
according to the maximum output power of the communications equipment.
Rated max. output
power of transmitter
(W)
Separation distance according to frequency of the transmitter (m)
150 kHz - 80 MHz 80 MHz - 800 MHz 800 MHz - 2.5 GHz
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
1 1.20 1.20 2.30
10 3.80 3.80 7.30
100 12.00 12.00 23.00
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in metres (m)
can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power
rating of the transmitter in watts (W) according to the transmitter manufacturer.
Note 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection
from structures, objects and people.
Pd 2.1
Pd 2.1
Pd 3.2
Sentier HC LLC (Hereinafter called Sentier) owns the intellectual property
rights to this Sentier product and this manual. This manual may refer to
information protected by copyrights or patents and does not convey any
license under the patent rights of Sentier, nor the rights of others.
Sentier intends to maintain the contents of this manual as confidential
information. Disclosure of the information in this manual in any manner
whatsoever without the written permission of Sentier is strictly
forbidden.
Contents of this manual are subject to changes without prior notice. All
information contained in this manual is believed to be correct. Sentier
shall not be liable for errors contained herein nor for incidental or
consequential damages in connection with the furnishing, performance,
or use of this manual.
© Copyright 2016 Sentier Health Connect. All right reserved.
Version: A September 2021
PN: 7100-1710
Sentier HC LLC
161 W Sunset Dr., Ste. 102
Waukesha, WI 53189 USA
www.sentierconnect.com
844-VETCORDER (844-838-2673)
