Sentinel BM-50 - Technical Specification

3.1. Technical specification
Parameter
Minimum
Typical
Maximum
Supply Voltage
11 V
12 V -32 V
34 V
Input resistance of digital and
analog inputs (except power
supply)
500 kΩ
Input Voltage Range:
Voltage 1
Voltage 2/3/4
30 V
60 V
Digital input Voltage threshold
5 V
Relay switching voltage
Relay switching current
60 VDC
1A
POWER SUPPLY: 12 to 30 V DC 4 W Max
ENERGY CONSUMPTION (12 V)*: Nominal: average 35 mA r.m.s,
OPERATION TEMPERATURE: -10 °C to +55 °C
STORAGE TEMPERATURE: -40 °C to +60 °C
STORAGE RELATIVE HUMIDITY: 5 to 95 % (no condensation)
* when internal battery is charged
