4. Pairing and configuring the Sentinel Hub
1 2
3 4
Tap the + sign at the top
of the screen.
Nearby device will be
shown. Select the
device.
Please make sure the
Sentinel HUB and the
Boat Monitor are close
enough to each other,
then press Continue.
Scan the QR code on the
HUB.
AC 110V/220 V
L
N
LOAD
(HVAC...)
12/24 V
SW1
SW2
IN 1
IN 2
Rsh hi
Rsh lo
RPM in
+Vbat
GND
GND
DATA
POWER
Temp.
probe
SW1
SW2
IN 1
IN 2
Rsh hi
Rsh lo
RPM in
+Vbat
GND
HUB
Magnetic
reed
switch
Power
relay
Example use case
3
6
