Section C – Troubleshooting, Service & Repair
No. on Diagram Product Code Description
50 H04018KF ¾" bsp Threaded Nipple – 45mm long
51 H03023 ¾" bsp f/f elbow
52 H030F46 ¾" bsp Threaded Socket
53 H030F11 ¾" bsp m/f elbow
54 H090F04 ¾" m x 19mm PP Hose adaptor
55 HH019X30 Clear Hose 19mm ID (per mtr)
56 H04018KA Flow Reverser Handle
57 H04018KB Flow Reverser Paddle
58 H04018KC Flow Reverser Body
59 H04018KD Flow Reverser Top Plate
60 H04018KE 'O' Ring for Reverser Top Plate
61 H03007 'O' Ring for Flow Reverser Paddle
62 MI022 M6 x 30mm Socket Cap Head Screw
70 H090F03 ¾" m x 20mm 90° Hose Adaptor
71 HH019X30 Clear Hose 19mm ID (per mtr)
72 H090F04 ¾" m x 19mm PP Hose Adaptor
73 H030HJ06 ¾" m x 20mm 'Y' piece Hose Adaptor
74 H190F16 ¾" x 19mm Water Inlet Tap
75 H090F06 ¾" f x ¾" m Brass Adaptor
77 H04024K JetFlush Hose Support Bracket
78 H090F01 ¾" Single Union L Port Valve
79 H04023K ¾" bsp Threaded Nipple – 35mm long
80 H04019K ¾" bsp Union
