Sentinel JetFlush Rapid User Manual

30 Jetflush Rapid V1- 02-15
EN
Section C – Troubleshooting, Service & Repair
JETFLUSH RAPID SPARES LIST
No. on Diagram Product Code Description
7 H04020K JetFlush Moulded Tank
8 H04021K JetFlush Tank Cap
9 H04022K JetFlush wheel (each)
9 H04022KA Axle for wheel (each)
20 H04002L22K JetFlush Motor 230v
21 H04012KA Fan cover
22 H04012KB Motor Fan
23 H03002B Motor Bearings
24 H03002F Motor Switch Box
25 H03002D22 Capacitor 230v
26 H01502C On/off switch for motor
27 H030HJ08 M8 x 40mm Brass Bolt
27 H030HJ07 M8 Brass Nut
27 H030HJ09 M8 Brass Washer
28 H03002A Motor Shaft Circlip
29 H03006 White Arnite Bush
30 H03007 Drive Shaft 'O' Ring
31 H04014K Drive Shaft Sleeve
32 H01507K M12 PP Bolt
33 H04013K Flange and Body
34 H0150211A Impellor 'O' Ring
35 H04015K Impellor
36 H04017K Rotor Cover
37 H04016K Rotor Cover 'O' Ring
38 H03012K M10 PP Bolt
