63 Jetflush Rapid
V1- 02-15
FR
Section C – Dépannage, entretien et réparation
LISTE DES PIÈCES DÉTACHÉES JETFLUSH RAPID
No. sur schéma Code produit Description
7 H04020K Réservoir moulé JetFlush
8 H04021K Bouchon de réservoir JetFlush
9 H04022K Roue JetFlush (unité)
9 H04022KA Essieu de roue (Unité)
20 H04002L22K Moteur JetFlush 220v
21 H04012KA Ventilateur
22 H04012KB Ventilateur de moteur
23 H03002B Supports de moteur
24 H03002F Commutateur
25 H03002D22 Condensateur 220v
26 H01502C Interrupteur moteur
27 H030HJ08 Boulon laiton M8 x 40mm
27 H030HJ07 Ecrou laiton M8
27 H030HJ09 Joint laiton M8
28 H03002A Anneau de sécurité du villebrequin
29 H03006 Bague blanche en Arnite
30 H03007 Joint torique pour moyeu
31 H04014K Manchon d’entrainement du moyeu
32 H01507K Boulon M12 PP
33 H04013K Bride et corps
34 H0150211A Joint torique de la roue
35 H04015K Roue
36 H04017K Capuchon du rotor
37 H04016K Joint torique du capuchon de rotor
38 H03012K Boulon M10 PP
