Horsepower .....................................................................3/4
Voltage ............................................................................120
Amp ..................................................................................4.8
Hertz ..................................................................................60
Phase ..........................................................................Single
RPM ..............................................................................3450
Cutting Wheel Diameter .................................................... 7"
Rip Capacity (tile size) ................................................... 18"
Diagonal capacity (tile size) ............................................ 12"
Maximum Depth of Cut ............................................... 1-3/8"
Stainless Steel Cutting Surface .......................19-7/8" x 15"
Overall Dimensions ...................... 22-5/8" x 17-5/8" x 6-7/8"
Net Weight ...............................................................22.93 lb
CUTTING WHEEL
The use of the provided 7" cutting wheel is recommended
for maximum performance and safety. Additional cutting
wheels of the same high quality are available at your
local dealer.
WARNING
Do not use cutting wheels rated less than 3450 RPM.
Failure to heed this warning could result in personal injury.
Only use continuous rim wheels, do not use serrated or
tooth edged wheels. Do not use wheel with cracks.
TABLE OF CONTENTS PRODUCT SPECIFICATIONS
SAFETY RULES 1
Work Preparation
Work Area Preparation
Tool Maintenance
Tool Preparation
ASSEMBLY 2
Unpacking
Tools Needed
To Install Cord Retainer
Cutting Wheel Assembly
To Install Splash Hood
To Install the Rip Guide
To Install the Miter Guide
To Fill Water Reservoir
Power Source
Grounding Instructions
Extension Cords
Motor
Electrical Connections
Position of the Tile Saw
OPERATION 8
ON/OFF Switch
Tool Placement
Making Cuts
To Make a Cross Cut
To Make a 45° Diagonal Cut
To Make a Miter Cut
To Make an L-Cut
To Make A Bevel Cut
Transportation
Cord and Wrench Storage
MAINTENANCE 12
General Maintenance
Lubrication
TROUBLESHOOTING 13
PARTS ILLUSTRATION & 14
LIST
WARRANTY 16
SECTION PAGE
