FigureA
FigureB
FigureC
GND
Circuit Grounding
Conductor
A
B
C
D
E
F
FOOD DEHYDRATING AT A GLANCE
This food dehydrator is equipped with a plug as shown in Figure A,
which should be used with the 120V three-hole receptacle in Figure
B. The plug must be properly inserted into the receptacle as shown
in Figure C.
Note:
Do not put the main unit into water or other liquids!
OPERATING INSTRUCTIONS
BEFORE USE
Control Panel
To start or stop the dehydrator
To +/- the temperature To +/- the timer
The indicator light of the dehydrator.
Every time you make a change of the
timer or temperature, the dehydrator will beep 1 time
Cleaning:
Wipe all parts of the equipment before use.
Clean the stainless steel tray, non stick silicone sheets and
storage bottles with a lightly dampened cloth.
Use detergent as needed. Always rinse with clean water.
Housing
Control Panel
Door
Trays
Fan
Heat pipes
F
E
A
C
B
D
To Next Page
