SC20 Series hand-portable radio
Item Description
1 Antenna.
2 Rugged Accessory Connector (sRAC). Attachment of audio accessories.
3 Audio Ports.
4 Alphanumeric Keypad.
5 Keypad Bezel.
6 Colour Bar.
7 Earpiece and microphone.
8 Navi-knob. A continuously rotating knob for adjusting the volume.
9 Digital Accessory Connector (sDAC). Used for charging the battery when mounted to the
radio, programming the radio and attachment of data accessories.
10 Battery release.
11 Battery.
12 External Antenna Connector.
Level 1 Service Guide 1
