Symbol Definition Symbol Definition
Read user manual before operation. See user manual
for instructions.
FAA Approved Symbol: The U.S. Federal Aviation
Administration (FAA) has approved this device for
use on-board commercial aircraft.
No Smoking Icon: Do not smoke near unit. Flow Setting Indicator
Warnings / ALERT (Yellow) Indicator Pulse Mode Operation
ALARM (Red) Indicator Device operating normally; power button
External Power Indicator Increase Flow Setting
Power Cartridge (battery) Status Gauge Decrease Flow Setting
Power Cartridge Symbol Use no oil or grease.
A
Amperes No open or naked ames.
Alternating Current No serviceable parts inside. Do not open cover.
IEC Icon for DC Power (Input) Warm Surface.
0
2
Oxygen Output Do not get wet.
Type B Applied Part (degree of protection against
electric shock)
Certied for both the U.S. and Canadian markets, to
the applicable U.S. and Canadian standards.
Recycle Symbol
This device complies with the requirements of
Directive 93/42/EEC concerning medical devices. It
therefore bears the CE marking as shown.
This symbol is to remind the equipment owners
to return it to a recycling facility at the end of its
life, per Waste Electrical and Electronic Equipment
(WEEE) Directive.
IPX1
Drip Proof Equipment-IPX1: The Eclipse Power
Cartridge (Battery), AC and DC Power Supplies
provide protection against the harmful effects of the
ingress of liquids. (IPX1, per IEC 60529)
Drip Proof Equipment-IPX0: The Eclipse enclosure
does not provide protection against the harmful
effects of the ingress of liquids. (IPX0, per IEC
60529)
Name and address of manufacturer
Authorized representative in the European
Community
User Controls & System Status Indicators
