Serpent F110 - Page 12

Page
23
Page
22
16
A
1/4x3/8
1/4x3/8
1/4x3/8
Note Spring washer
orientation.
Spur gear is NOT
INCLUDeD in the
kit. Assemble the
proper Spur for your
set-up.
1
2
17
A
Bag
5
1/4x3/8 Flanged
1/4x3/8 Flanged
Note insert orientation. Assemble
as basic setup for rubber tyres 0/20
insert.
1
2
3
M3X3
6.5x8x0.25
6.5x8x0.25
HOW TO ADJUST THE BALL-DIFF: In order to tighten
or loosen the ball-diff, you should follow the next two
steps:
1
2
Push a pin or a
Allen tool through
the Diff Hub slot
into the hole of the
adjusting nut
Turn clockwise
to tighten or
anticlockwise to
loosen the ball diff
