Page
10
SHIFT POINT
SCREW
SHIFT POINT
SCREW
M3x3
M3x10
M3x10
M3x3
M3x6
M3x6
1
1
2
3
2
3
5x5
5x5
NOTE:
Screw in all the way,
then unscrew 3 turns
NOTE:
Screw in all the way,
then unscrew 3 turns
18.1 18.2
18.3
GEARBOX ASSEMBLY
2.5x12
1
2
STEP
18
STEP
19
R5
