Page
12
STEP
22
STEP
23
STEP
24
M3x12
M3x6
M3x6
M3x4
M3x4
M3x12
1mm
1mm
FRONT ASSEMBLY I
Bag
5
Note: Front bearing blocks are
not symetric
Note: Front suspension brackets
are not symetric
