8
INSTALLATION
PRE-INSTALLATION CHECK LIST
When installing any system, first make sure the major components are available. Generally the major components
necessary for an installation are:
Pre-mix system:
CO
2
regulator set
Product connectors for Figal tank
Gas connectors for Figal tank
Beverage dispenser
Beverage tubing
CO
2
tank
Figal beverage tanks
Stepless (Oetiker) clamps
Chain for CO
2
tank
Post mix system:
CO
2
regulator set
Beverage dispenser
Beverage tubing
CO
2
tank
Carbonator
Stepless (Oetiker) clamps
Chain for CO
2
tank
Double Check:
Do you have enough space to install the dis-
penser or a dispenser and top mounted cuber?
Does the top mounted cuber (if utilized) have a
minimum of 6 inches (15.3) cm) clearance on
all sides?
Is the countertop level?
Can the countertop support the weight of the
dispenser, or the dispenser/cuber combination
plus the weight of the stored ice?
Also consider the location of the following items before installation:
Figal system also:
Syrup connectors for Figal tank
Gas connectors for Figal tank
Figal syrup tanks
B-I-B System also:
B-I-B connectors
B-I-B regulator set
B-I-B rack
B-I-B syrup boxes
Do you have enough space to install the dis-
penser or a dispenser and top mounted cu-
ber?
Does the top mounted cuber (if utilized) have
a minimum of 6 inches (15.3) cm) clearance
on all sides?
Is the countertop level?
Can the countertop support the weight of the
dispenser, or the dispenser/cuber combination
plus the weight of the stored ice?
Water line
Drain
Power outlet
Heating and air conditioning ducts
LEGS
Legs are optional equipment with most Servend dispens-
ers. Standard legs are four-inch (10.2 cm) tall painted
steel legs.
When installing legs on a MD Series dispenser, leg
braces should be used. These are metal braces fitting
side to side under the dispenser that reinforce the leg
attachment area.
CAUTION:
It is recommended if an icemaker is installed on top of the dis-
penser, legs should NOT be installed.
