SET 1501 T - Enclosure Dimensions

10
Product description: Enclosure dimensions
Enclosure dimensions
308
SET 3501 T - 1488
SET 2501 T - 1154
SET 1501 T - 1004
695
434,2
59,2
770
75
-
27904g
SCALE: NOT TO SCALE
MATERIAL:
THICKNESS:
WEIGHT:
REV. BY:
DATE:
REF.:
DATE:
PART NO REV.:
REV.:
PART NO
Sheetmetal atstate is based on Dantherm Air Handling A/S
process equipment and is only intended as a guide.
8
This Drawing is furnished with the understanding that the
essence there of will not be reproduced in whole or in part
without written authorization by Dantherm A/S.
All designs originated by Dantherm A/S are the
property of said Company and will be protected by Patents.
Surface appearance according to reference
table LZT 142 0001, category
Linear dimensions without tolerances according to
DS/ISO 2768-m. Angular dimensions without tolerances: ± 1°
308
Fig. 4
SET 1501 H -
SET 2501 H
SET 3501 H
Fig. 5
SET (T)
308
SET 3501 T - 1488
SET 2501 T - 1154
SET 1501 T - 1004
695
434,2
59,2
SET (H)
