SET SET-2090 - J1, J2 Pinout (Front); J1 Connector Pin Assignments; J2 Connector Pin Assignments

4 of 10
www.smart-e-tech.com
SET-2090
Technical Description
Issue 05 02.06.23
INTERNAL - NI CONFIDENTIAL
15
30
44 14
29
43 13
28
42 12
27
41 11
26
40 10
25
39 9
24
38 8
23
37 7
22
36 6
21
35 5
20
34 4
J1, J2 Pinout (Front)
J1 J2
Signal
Description
Px.y
Line y Port x
GND
Ground connection
NC
No connection
J1, J2 Connector Pin Assignments
15
30
44
14
29
43
13
28
42
12
27
41
11
26
40
10
25
39
9
24
38
8
23
37
7
22
36
6
21
35
5
20
34
4
19
33
3
18
32
2
17
31
1
16
P3.2+
P3.2-
P3.1+
P3.1-
P3.0+
P3.0-
NC
NC
P2.2+
P2.2-
P2.1+
P2.1-
P2.0+
P2.0-
J1_Spare
GND
P1.2+
P1.2-
P1.1+
P1.1-
P1.0+
P1.0-
NC
NC
P0.2+
P0.2-
P0.1+
P0.1-
P0.0+
P0.0-
P3.3+
P3.3-
REF_3
REF_2
P2.3+
P2.3-
GND
GND
P1.3+
P1.3-
REF_1
REF_0
P0.3+
P0.3-
15
30
44
14
29
43
13
28
42
12
27
41
11
26
40
10
25
39
9
24
38
8
23
37
7
22
36
6
21
35
5
20
34
4
19
33
3
18
32
2
17
31
1
16
P7.2+
P7.2-
P7.1+
P7.1-
P7.0+
P7.0-
NC
NC
P6.2+
P6.2-
P6.1+
P6.1-
P6.0+
P6.0-
J2_Spare
GND
P5.2+
P5.2-
P5.1+
P5.1-
P5.0+
P5.0-
NC
NC
P4.2+
P4.2-
P4.1+
P4.1-
P4.0+
P4.0-
P7.3+
P7.3-
REF_7
REF_6
P6.3+
P6.3-
GND
GND
P5.3+
P5.3-
REF_5
REF_4
P4.3+
P4.3-
