LED Behavior
LED Name
LED Behavior
Definition of Behavior
PWR
Off
No power present on the board
Solid green
Power good state
RDY
Off
Module card is unpowered
Solid green
Card is recognized by the chassis and ready to
communicate
Solid amber
Module card is booting
Blinking
amber
Chassis is communicating with the module card
Error Handling
LED Name
LED Behavior
Actions
PWR
Off
- Checking the power supply of the chassis
- Checking the external power supply if used
RDY
Off
- Checking the power supply of the chassis
- Checking the external power supply if used
Solid amber
- Waiting till boot process is finished
Blinking
amber
- Waiting till communication is finished
- if communication does not finish, shut down all
operations and reboot chassis
Hardware Specifications
Absolute Maximum Ratings
Property
Condition
Value
Comment
Relative humidity
5% to 95%
Non-condensing
Temperature
0°C – 85°C
Storage
-40°C-85°C
Max. Input Voltage
Any Pin
60 Vdc
Limited by connector
Min. Input Voltage
Any Pin
-60 Vdc
Limited by connector
Max. Current rating
1.5 A
2 A transient
