Setcom 900 Series - Page 5

(a) Charging Jack
DC input power (7 to 24Vdc)
(f) Portable Radio
Push-to-Talk
(e) Portable Radio
Interface Connector
(c) Volume Control
Also Power On/ Off
(d) Mobile Radio
Push-to-Talk
(b) LED Indicator
CSB-900W3
SN: SXXXXXXXXX
Figure 1
900 Series Wireless Headset
Third Generation
(rear view)
(g) Headset Antenna
(h) Cell Phone
Button
