900W3-BASE
SN: Sxxxxxxxxx
Figure 2
900 Series Wireless Base Station
Third Generation
(side view)
(side one) (side two)
(a) LED Indicator (a) LED Indicator
(b) Pairing Button(c) Power Cable Connector
DC input power (7 to 24Vdc)
(d) Adapter Cable Connector
(e) Base Station Antenna
