36
11 DIP Switch Configurations
12345678
ON
12345678
ON
12345678
ON
12345678
ON
12345678
ON
12345678
ON
Position 7 ON
Most MOTOROLA and M/A-COM
(ERICSSON, GE) Radios
100mV into 560 ohms
(factory default setting & when used with a RIM-900-BAL)
Position 4, 7 ON
Position 4, 6, 8 ON
12345678
ON
Position 6, 8 ON
Position 7, 8 ON
Position 4, 7, 8 ON
Position 5, 7, 8 ON
MIDLAND Mobile Radios
310mV into 270 ohms
STANDARD Mobile Radios
8-10mV into 600 ohms
KENWOOD and UNIDEN
Mobile Radios
5mV into 600 ohms
MOTOROLA MCX-100 via MAC-9MH
100 mV into 560 ohms. NO bias on mic
line. Also BENDIX/KING LMH series with radio cable
KENWOOD -90 (KN, KO) Series
Mobile Radios: 30 mV
Low-Level/High-Level combination,
e.g. KENWOOD and MOTOROLA
via RSM-90X
IM-900/E DIP Switch Configuration
= Switch OFF
= Switch ON
