VOLTAGE
DISPLAY
12V 24V
PROTECTION
POSITION
LOW
1 Bar
9.6 10.9 21.3 22.7
MIDDLE
2 Bars
10.4 11.7 22.8 24.2
HIGH
3 Bars
11.1 12.4 24.3 25.7
Battery Protection Level
BATTERY PROTECTION MODE
In the standby status, long press “on/off” and “setting” button at the same time for 3 seconds
to enter the battery protection setting menu. Press “+” and “–” to adjust the level, “- -” refer to
the low mode, “= =” refer to the middle mode, and “≡ ≡” refer to the high mode.
04
The Fridge/Freezer is designed to operate on DC voltage inputs.
DC input 12V or 24V
DC cable
2.5m,16AWG
● Connect the feeding cable to a direct current 12/24V DC power source.
● Make sure the polarity is right.
● If connected to an existing cigarette plug, please carefully check up that power supply is sufficient.
● If the supplied power cable is not used, please see the table containing the information related to the
cable section:
HOW TO USE THE REFRIGERATOR
1.Connecting with 12V or 24V
2.Connecting with 110-240V
● FC12/20 could connect with 110-240V via AC adapter.
● The coolers have an integrated multi-voltage power supply with priority circuit for connecting
to an AC voltage source of 110-240V. The priority circuit automatically switches the cooler
to mains operation, if the device is connected to a 120/240V AC mains, even if the 12/24V
connection cable is still attached. In order to protect the freezer and cigarette socket, we
suggest use with one power supply.
Do not put hot food items into the refrigerator. Place the products in such a way as to avoid them hitting against
each other or breaking because of the movement of the vehicle.
Make sure that the lid is always well closed and open it for as short a time as possible.
4.FILLING
