Alarm Matrix
The SRCM has a great deal of flexibility to define alarm conditions. Alarms and
warnings can be configured for primary and secondary rooms, and for the door.
Room display can toggle between Primary and Secondary. The following table
outlines what will occur in terms of priority and display under normal and alarm
conditions.
N=Normal; A=Alarm
Toggle High Priority Display
Text (Maxi-
mum eight
characters)
Background Remarks
Primary
Pressure
Secondary
Pressure
Disabled N N Normal Green Displays primary pressure or
secondary pressure based on the
selection
Disabled N A Alarm Red
Disabled N A Alarm Red Pressure has higher priority
Disabled N A Alarm Red Pressure has higher priority
Disabled N A Alarm Red Pressure has higher priority
Disabled A N Alarm Red If Primary Room is selected in the
pressure to display
Disabled A N Alarm Red
Disabled A N Alarm Red 1.Pressure has higher priority.
2.Corresponds to Primary Room/
Secondary based on the selection
by the user.
Disabled A N Alarm Red
Disabled A A Alarm Red
Disabled A A Alarm Red
Disabled A A Alarm Red
Disabled A A Alarm Red
Enabled N N Normal Green Toggle between primary and
secondary.
-18-
