D07-[t] [g,g,g] [r,r,r,r] [f,f] [s] [m] [d]
[f,f] –Inlet and Outlet Fittings
-[AA ] Swagelokφ3mm
-[GG] Swagelokφ6mm
-[BB ]
Swagelok 1/8"
-[CC ]
Swagelok 1/4"
-[MM] VCR 1/4"
-[XX ]
Customer Special fittings (please consult [d] for detail)
[s] –Seal Materials
-[ V ] Viton
-[ N ] Neoprene
[m] –Mounting Position
-[ H ] Horizontal
-[ E ] HESD(Horizontal Edge Side Down)
-[ U ] Vertical Inlet Up
-[ D ] Vertical Inlet Down
[d] –Description
-[ ] Default Value：
The letters on cover and tag：in Chinese
Differential Pressure：D07-7B： (0.1 ~ 0.5) MPa (14.5~72.5 psid)
D07-7BM：<0.01MPa (1.5psid)
Max Operating Pressure： 3 MPa (435.1 psig)
Calibration Temperature：(22±2)℃
-[ S ] Customer Special Requirements：
For Example：The letters on cover and tag：in English；Customer Special Full Scale:9SLM；The proportion
of Mixture gases should be indicated：N
2 (60%) + CO2(40%)；Customer Differential
Pressure：(0.05 ~ 0.3) MPa；Customer Calibration Temperature：40℃ and other customer
special requirements.
For Example: D07-7B007001LCCNUS
D07-7B 007 001L CC N U S
