Wi-Fi interface
Sevio Basic is a radio device operating at 2.4 GHz WLAN bands, and configured either as Access Point or
Client. Sevio Portal, the web application for the Sevio system, can be used to configure and view the status
of the Wi-Fi interface.
The antenna might be fixed to the antenna connector directly or using antenna cable fixed
to the antenna connector.
Note: only approved antennas can be used.
Parameter Value
Type of Radio interface IEEE 802.11b/g/n 2.4 GHz (Wi-Fi)
Operating Frequency Bandwidth/s 2412MHz - 2472MHz
Number of channels 13
Radio Frequency Power < 17 dBm EIRP
Antenna connector RP-SMA female
Antenna type External provided, RN-SMA-S-RP model, gain max: 0.56 dBi
USB
The USB port may be used for a Cellular Internet connection through Sevio M100 adapter (not included).
The USB port may also be used to configure the Sevio Router when offline through a properly set up USB
flash drive (see chapter Changing parameters offline).
Standard 2.0
USB Type A
Max. Current 500 mA
Document ID: basic_installation_guide_en 13
