6
Inspection and Maintenance
Checking the friction ring
34
Operating Instructions – Explosion-Proof VARIMOT
®
Variable Speed Gear Units and Accessories
6.4 Checking the friction ring
52024AXX
Fig. 14: Checking/replacing friction ring
[1] Shaft [8] Housing
[2] Retaining screws [9] Hollow shaft
[7] Needle roller bearing [10] Friction ring
52025AXX
Fig. 15: Checking/replacing friction ring
[3] Flange [6] Drive disk
[4] Adjusting plate [16] Retaining screw
[5] Housing cover
[
8
][
7
][
10
]
[1]
[2]
[9]
[3] [16]
[6] [5] [4]
