5
1
DESCRIPTION
This macerator is manufactured in
a factory which is quality certifi ed to
ISO 9001(2000) accredited by AFAQ.
Installed and used correctly, the unit
will give consistent and reliable ser-
vice.
This device is not designed for
persons (including children)
with limited physical, sensory or
mental abilities, or those with minimal
experience and knowledge, unless
they are monitored and are given
the necessary instructions for using
the device, with the help of a person
responsible for their safety. Monitor
children and make sure they do not
play with the device.
2
APPLICATIONS
This appliance is a compact lifting
station designed to evacuate sewage
from private dwellings.
3
INSTALLATION
The unit should be accessible for
possible service.
The fi tting and working of your ap-
pliance must meet local regulations
and the EN 12056-4 standard.
CONNECTION TO THE ELECTRICAL
SUPPLY
The electrical installation
should be carried by a qualifi ed
person.
The unit should be connected to a fully
earthed electrical supply. All wiring must
conform to BS7671, 1992 require-
ments for electrical installations. The
unit requires a 220/240V single phase
AC 50 Hz supply (UK specifi cation).
Do not connect the unit to a conventional
plug and socket. It must be wired into
a fused, unswitched, fi xed wiring
connector fi tted with a 5 amp fuse.
The wires in the mains lead are coloured
in accordance with the following code:
Brown - Live
Blue - Neutral
Green/Yellow - Earth
Warning: Ensure the electricity is
turned OFF at the main switch board
before wiring to connector.
All work on cable, pressure chamber
and motor should only be carried out
by a qualifi ed Sanifl o servicing agent,
as special tools are required.
This appliance conforms to EN
12050-3 and the European stan-
dards concerning electrical safety
and electromagnetic compatibility.
WC checking that all seals, and
connections are watertight.
Check both the discharge pipework
from the unit and the other sanitary
appliances connections.
5
MAINTENANCE
WARNING !!! If away for a long
period, we recommend that you turn
off the water supply to the WC served
by the unit.
CARE OF YOUR UNIT
In order to remove scale and clean
the macerator and the bowl, use a
household descalent (like SANIFLO
Descaler).
6
FAULT FINDING / REMEDIES
If the problem cannot be easily remedied in this way, please
call our Service organisation.
ALL WORK INVOLVING DISMANTLING OF THE APPLIANCE
MUST BE CARRIED OUT BY AN APPROVED REPAIR AGENT
SYMPTOMS PROBABLE CAUSES REMEDIES
• The motor does not activate • The electrical power supply
is not active
• The electrical power supply is
defective
• The motor or the control system
is defective
• Restore the electrical supply
• Check the electrical power
supply
• Otherwise, ask an approved
repair agent to intervene
• The motor emits a rattling or
crunching sound, hums, but
does not run
• Foreign object into the box
• Problem with the motor or the
control system
• Remove the foreign body
• Otherwise, ask an approved
repair agent to intervene
• The motor intermittently
activates
• The connected sanitary devices
are leaking
• The non-return valve is faulty
• Check the installation upstream
• Clean or replace the non-return
valve
• The motor operates normally, but
continues to run for a long time
• The length or height of the
installation is over the
specifi cation, or there are too
many bends/elbows
• The pump cover plate is
occluded
• Check the installation
• Otherwise, ask an approved
repair agent to intervene
• The unit stops • The unit has been running for
too long (thermal cut-out)
• Wait for reset, then ask an
approved repair agent to
intervene
• Motor is surging and water
in the WC pan goes down
very slowly
• The air dispenser is clogged up
• Problem with motor
• Clear the air dispenser hole
• Otherwise, ask an approved
repair agent to intervene
• Cloudy water comes up into
the shower basin (units with
side inlets)
• Shower installed too low as
compared with the macerator unit
• Hinged side inlet discs
clogged up
• Check the installation
• Clean the hinged discs
• Otherwise, ask an approved
repair agent to intervene
IN ALL CASES, YOU MUST DISCONNECT
THE MACERATOR FROM THE POWER SUPPLY
7
GUARANTEE
2 years guarantee as from its date of purchase subject to correct installation and
correct use.
4
COMMISSIONING
THE UNIT
Once electrical and plumbing con-
nections have been made, fl ush the
UK
