BR PRESSURE WASHER OPERATOR’S MANUAL
13
ITEM PART NO. DESCRIPTION QTY.
1 95-07104020 Frame, Welded Cage Assy
16/20/24 HP (404021, 404027,
503021, 503027, 405031,
405037, 505031, 505037) 1
95-07104003 Frame, Welded Cage Assy 11/13
HP (353031, 353037, 353531,
353537, 304031, 304037) 1
2 10-02025A Label, "Hot/Caliente" Warning 1
3 77-VHLM4 Muffler, Honda GX620 20 & 24 HP
(405031, 405037, 505031,
505037) 1
76-807964 Muffler, Briggs 16 HP (404021,
404027, 503021, 503027) 1
4 7-01434 Insulation, Muffler Guard 1
5 95-07104029 Shield, Heat, Muffler Guard,
Honda 20/24 HP (405031,
405037, 505031, 505037) 1
95-07101214 Shield, Heat, Muffler Guard,
Vanguard 16 HP (404021,
404027, 503021, 503027) 1
6 10-02011 Label, Gasoline Only 1
7 10-02029 Label, Danger Cool Engine 1
8 5-1660 Pump, Legacy TT-3540
(353037, 353537) 1
5-1665 Pump, Legacy KT-4040
(304037, 404027) 1
5-1661 Pump, Legacy TT-3555 (503027)1
5-1668 Pump, Legacy HDL-5050
(405037, 505037) 1
5-23040 Pump, General, TS-1011
(353031, 353531) 1
5-2307 Pump, General, TS-2021
(503021) 1
5-2320 Pump, General, T-9281
(304031, 404021) 1
5-2331 Pump, General, T-5050
(405031, 505031) 1
9 90-102751 Bolt, 1/2" x 3-1/2", NC HH 1
10 90-3096 Washer, 1/2", Flat 1
11 90-18012 Screw, 1/4" x 5/8",
PHIC PH MS 4
12 90-40011 Washer, 5/16", Flat, Cut 4
13 7-80320 Shut Off Valve, Fuel Tank 1
14 2-010061 Grommet, Fuel Tank 1
15 90-100543 Screw, 5/16"-18 x 3/4"
M PH TRH 4
ITEM PART NO. DESCRIPTION QTY.
16 90-4001 Washer, 5/16", Flat, SAE 4
17 90-2001 Nut, 5/16" ESNA, NC 4
18 2-00471 Plug, 1/8" Square Head, Black 1
19 95-07104023 Bracket, Pump & Belt Guard
(4050, 5050) 1
95-07104035 Bracket, Pump & Belt Guard
(All Models Except 4050, 5050) 1
20 11-3218 Label, Nozzle 1
21 2-01041 Pad, Soft Rubber, 50 Duro 2
22 90-1021 Bolt, 3/8" x 2-1/2", NC HH 2
23 90-40125 Washer, 3/8" x 1" Steel 2
24 90-4002 Washer, 3/8", Flat, SAE 2
25 90-2002 Nut, 3/8" ESNA, NC 2
26 2-0103 Grommet, Rubber,
Nozzle Holder 5
27 5-0105 Engine, Honda, 11 HP
(353031, 353037) 1
5-010721 Engine, Honda, 13 HP
(353531, 353537) 1
5-0306 Engine, Vanguard 16 HP Pull
Start (404021, 404027, 503021,
503027) 1
5-01093 Engine, Honda, 20 HP, E/S
(405031, 405037) 1
5-01094 Engine, Honda 24 HP E/S
(505031, 505037) 1
28 4-0307 Wheel & Tire Compl. 6" Steel 2
29 90-4005 Washer, 5/8" Flat SAE 2
30 90-20041 Collar, 5/8" 2
31 90-40181 Washer, Nylon Spacer, 0.656 2
32 95-07104032 Axle Spacer,
.875" OD x 2.0 Pipe 2
33 95-07104723 Axle, 5/8" x 27.80"L
(353031, 304031, 304037,
353037, 353531, 353537) 1
95-07101012A Axle, 5/8" x 28.5" (404021,
404027, 503021, 503027, 405031,
405037, 505031, 505037) 1
34 90-19925 Screw, M6 x 20mm, BH, SOC,
Black 4
35 90-40001 Washer, 1/4", Flat, SAE, Black 4
36 2-9016 Clamp, Round, 0.56 ID 1
37 11-0316 Label, Instructions 1
MACHINE ASSEMBLY
SIDE VIEW PARTS LIST
