Xpert HD-DD-PD-DA-RG • 8.780-000.0 • Rev. 07/13
11
PRESSURE WASHER
SERVICE MANUAL
G.1 SERIES PUMP EXPLODED VIEW PARTS LIST (CONT)
ITEM PART NO. DESCRIPTION QTY
39 9.804-585.0 Crankshaft Seal 1
40*
See Kit Below Plunger Nut 3
41*
See Kit Below Copper Spacer 3
42* See Kit Below Plunger, 15mm 3
43*
See Kit Below Copper Spacer 3
44*
See Kit Below O-Ring Ø1.78x5.28 3
45*
See Kit Below Tefl on Ring 3
46 9.803-964.0 Plunger Rod 3
47 9.803-965.0 Connecting Rod Pin 3
45 9.803-966.0 Connecting Rod 3
49 9.803-218.0 Spring Washer 6
50 8.933-020.0 Connecting Rod Screw 6
54 9.803-969.0 O-Ring 2.62 x 107.62 1
53 9.803-968.0 Crankcase Cover 1
52 9.803-197.0 Gasket, G3/4 1
51 9.803-202.0 Sightglass G3/4 1
* Part available in kit (See below)
REPAIR KIT
NUMBER 8.725-354.0 8.725-355.0 9.803-934.0 9.803-936.0 9.803-937.0
KIT DE-
SCRIPTION
Plunger Seal
15mm
Complete
Seal Packing 15mm Plunger 15mm Complete Valve
Plunger Oil
Seals
ITEM NUM-
BERS
INCLUDED
3, 5, 7, 8, 9
3, 4, 5,
6, 7, 8, 9
40, 41, 42, 43,
44, 45
13, 14, 15 2
G.1 SERIES PUMP REPAIR KITS
