Xpert HD-DD-PD-DA-RG • 8.780-000.0 • Rev. 07/13
PRESSURE WASHER
SERVICE MANUAL
6
EXPLODED VIEW PARTS LIST (CONT)
ITEM PART NO. DESCRIPTION QTY
29 9.802-166.0 Coupler, 3/8" Female, Brass 1
8.702-088.0 ▲O-Ring, Viton, 3/8” 1
8.707-182.0 Coupler, Twist Connect,
M22-Fx3/8"" FNP
(163cc) (Legacy Models) 1
8.704-036.0 ▲O-Ring, Viton, Twist Connect 1
30 9.138-438.0 Shark branding label
(DD Models) 1
31 8.930-124.0 Label, Intended for Outdoor Use -
Serial - Specs
(All Models Except 187cc RG) 1
32 9.800-008.0 Label, Danger Cool Engine
(All Models Except 187cc RG) 1
33 9.800-006.0 Label, Hot/Caliente w/Arrows
(All Models Except 187cc RG) 1
34 8.751-096.0 Label Regulation 4442.6 1
35 8.783-034.0 Label, Quick Start Guide 1
(196 cc & 208 cc Models) 1
8.783-037.0 Label, Quick Start Guide 2
(163 cc) (Legacy &
Comet Pump Models) 1
9.138-408.0 Quick Start Instruction
Guide Sticker
(187cc) (RG Model) 1
36 8.750-809.0 Label, Operator
Warnings Trilingual 1
8.783-035.0 Label, Operation Warnings
Trilingual (187cc)-(RG Model) 1
37 8.783-036.0 Label, Warning Pictogram
(All Models Except 187cc RG) 1
38 8.783-038.0 Label, Universal DB Rating,
Ear Protection, Trilingual
(All Models Except 187cc RG) 1
39 9.802-216.0 Injector, Chem, Non Adj, 0.083
(G Series Pump Models) 1
40 6.388-216.0 ▲ Hose DN 5 1
41 5.731-652.0 ▲ Filter with weight 1
42 9.802-958.0 ▲ Shaft Key, 0.185 SQR X 1.75"
(All Models Except
Comet Pump Models) 1
9.194-883.0 ▲ Shaft key 3/16''SQx1.5''
(187cc)-(RG Model) 1
43 9.198-003.0 5/16 Internal L/W
.332 ID X .620 OD ZINC
(187cc)-(RG Model) 2
44 9.138-313.0 Caution Engine
Oil Tag-Trilingual
(187cc)-(RG Model) 1
45 9.801-590.0 Rating Plate, RG-253037 1
46 8.753-554.0 Label, Rate Specs, Middle
(187cc)-(RG Model) 1
▲ Not Shown
To Next Page
