4 TOLL FREE: 1-800-798-7398 5www.sharkclean.com
10 To carry the vacuum:
With the unit in the standing
position, lift by the Dust Cup
Assembly Handle (carry handle).
CAUTION: When lifting or
carrying, DO NOT press Dust
Cup Assembly release button.
Along with your upright unit, you
will find the following components:
a Vacuum Body
b Floor Power Nozzle
c Handle Assembly
d Super Stretch Hose
e Cleaning Wand
f Pet Hair Power Brush
g Cleaning Attachments
*
Note: Optional tools are available for sale
for any NV26 or NV27 model:
1-800-798-7398.
Your Shark Navigator
®
Upright
is easy to assemble:
1 Lay your vacuum body on a
level surface.
2 Slide the electrical connection
from the power nozzle into the
main body to click into place.
3 Connect the hose from the main
body to the power nozzle; push
with a slight turning motion to
create a snug fit.
4 Slide the handle assembly
into the upright unit aligning
the hose hook on the handle
assembly with the power cord
hooks on the back of the unit.
5 Secure the handle assembly in
place with included bolt.
6 Place the vacuum in the upright
position.
7 Store the Crevice Tool, Dusting
Brush and Cleaning Wand on
the unit.
8 Attach the Super Stretch Hose:
a) Snap hose into swivel
connector
b) Route under anti-tip hook
c) Route over upper hose
holder
d) Press securely onto cleaning
wand
IMPORTANT:
To prevent vacuum from
tipping, secure hose under the
anti-tip hose hook.
9 When storing your vacuum,
wind cord around the two cord
holders and secure with cord
clip:
• Quick Cord release at the
top of the unit – place in the
upright position.
• Second holder near the
base – turn until it is pointing
down.
To release the cord, turn the Quick
Cord release to the left or right.
IMPORTANT:
For suction to reach the Floor
Power Nozzle, the Cleaning
Wand and Super Stretch Hose
must be attached securely on
the vacuum body.
a c
c
e
7
8 9
Getting Started
g
b
f
d
d
b
a
4
5
3
2
