4 TOLL FREE: 1-800-798-7398
Along with your upright unit, you will find the
following components:
a Handle Assembly
b Cleaning Attachments
c Extra Filters
d Super Stretch Hose
e Floor Power Nozzle
f Vacuum Body
g Cleaning Wand
*
Note: models NV22C, NV22L, NV22LC, NV22P,
NV22T, NV22Q and NV22W include the optional Pet
Hair Power Brush (
h
). NV22L, NV22P, NV22T, NV22Q,
and NV22W include the optional extra 24" crevice tool
(
i
). NV22Q includes the optional extra 10’ strech hose
(
j
).These tools can be stored in separate accessory bag.
Optional tools are available for sale for any NV22
model: 1-800-798-7398.
Your Shark
®
Upright is easy
to assemble:
1 Lay your vacuum body on a level
surface.
2 Slide the electrical connection from
the power nozzle into the main body
to click into place.
3 Connect the hose from the main
body to the power nozzle; push with
a slight turning motion to create
a snug fit.
4 Slide the handle assembly into the
upright unit aligning the hose hook
on the handle assembly with the
power cord hooks on the back of
the unit.
5 Secure the handle assembly in place
with included nut/bolt (shipped
attached to handle assembly).
6 Place the vacuum in the upright
position.
7 Store the Crevice Tool, Dusting
Brush and Cleaning Wand on
the unit.
Getting Started
g
h
i
j
2
3
4
5
7
