4 TOLL FREE: 1-800-798-7398
Getting Started
4
5
3
7
2
Your Shark
®
Navigator Upright
is easy to assemble:
1 Lay your vacuum body on a level
surface.
2
Slide the electrical
connection from the power
nozzle into the main body to
click into place.
3 Connect the hose from the main
body to the power nozzle; push
with a slight turning motion to
create a snug fit.
4 Slide the handle assembly into
the upright unit aligning the
hose hook on the handle
assembly with the power cord
hooks on the back of the unit.
5 Secure the handle assembly in
place with included nut/bolt
(shipped attached to handle
assembly).
6 Place the vacuum in the upright
position.
7 Store the Crevice Tool, Dusting
Brush and Cleaning Wand on the
unit.
Along with your upright unit, you
will find the following components:
a
Vacuum Body
b Floor Power Nozzle
c Handle Assembly
d Super Stretch Hose
e Cleaning Wand
f Pet Hair Power Brush
g Cleaning Attachments
*
Note: Optional tools are available for
purchase: 1-800-798-7398.
a c e
g
b
f
d
