Shark NV44 - Getting Started; Component Identification; Vacuum Assembly

4
TOLL FREE: 1-800-798-7398
Along with your upright unit, you
will find the following components:
a Vacuum Body
b MotorizedFloorBrush
c Handle Assembly
d Super Stretch Hose
e Cleaning Wand
f Power Brush
g Cleaning Attachments
Getting Started
d
Your Shark
®
Navigator
®
Plus
Upright is easy to assemble:
1 Lay your vacuum body on a
level surface.
2 Slide the electrical connection
from the motorized floor brush
into the main body to click into
place.
3 Connect the hose from the
main body to the motorized
floor brush; push with a slight
turning motion to create a snug
fit.
4 Slide the handle assembly
into the upright unit aligning
the hose hook on the handle
assembly with the power cord
hooks on the back of the unit.
5 Secure the handle assembly in
place with included nut/bolt
(shipped attached to handle
assembly).
6 Place the vacuum in the upright
position.
7 Store the Crevice Tool, Dusting
Brush and Cleaning Wand on
the unit.
a c e*
g
b
f
4
5
3
2
7
