7.2 The user interface (main window)
A – Filemenu:seeg.1.
B – Thecurrentconguration’sname.Viathelemenuanynumberofcongurationswithveproles
  eachcanbecreatedandedited(seeg.1).
C – Prolemenu:uptoveprolescanbesavedonthemouse’sinternalmemory,selectthemfromthis
  dropdownmenu(g.2).
D – Renamethesingleproleshere.
E – Buttonconguration:eachmousebuttoncanbeassigneddifferentfunctions,selectthesefunctions
  fromtherespectivedropdownmenu(see7.3).
F – Functiondenition:Fromthispulldownmenuselectthedesired,pre-denedfunctiontoassignitto
  thebutton.
G– Thistextelddisplaysthepre-denedfunctiondescription.Thisdescriptionmaybechangedany
time.
H – Clickingthisbuttonwillclosetheeditorwithouttransferringthechangestothemouse.
I – Clickingthisbuttonwilltransferallchangesmadeinsidetheeditortothemouse,theeditorwindow
remains open.

A B C D
E F G
H
I
