6.4 The LED indications of the Sound Control Unit
The SCU supports the sound input formats "Stereo" and "Dolby
®
Digital 5.1".
   BoththesesignalscanbeconvertedintoaDolby
®
Headphone output signal by the SCU.
   Astheinputsignalisdependingonthemedium(game,movieetc.)used,werecommendyoutocheck
   thepackageand/ordocumentationofthemediumusedtondinformationaboutthesupportedsound
modes.
   Furthermoretheinputsignaldependsontheselectedplaybackmodeoftheplaybackdevice(console,
DVD player etc.). Please refer to the respective documentation of the playback device to make the
correct settings.
The SCU offers two different playback modes for the reproduction of Dolby
®
Headphone signals.
These playback modes are different in tone color and sound impression. The gaming mode focuses on
heavy basses so especially in-game sound effects are accurately reproduced.
In contrast the music mode of the SCU offers a well-balanced tone color which is recommended for
music listening.
Depending on the input and output signals the LEDs of the SCU will illuminate in different combinations
and colors:

