Sharkoon X-Tatic SR - SCU Status: Switched Off; SCU Status: Stereo Input Signal

6.4.1 SCU switched off

6.4.2 Stereo input signal

SCU switched off
SCU switched on
Input signal: stereo
Output signal: stereo
SCU switched on
Input signal: stereo
Output signal: Dolby
®
Headphone in gaming mode
SCU switched on
Input signal: stereo
Output signal: Dolby
®
Headphone in music mode
SCU switched on
Input signal: stereo
Output signal: stereo
7
2x
1x
3x
